Lifting capacity : 750
kg
Main beam : 120 x 80 x 5 mm
Lifting gear hydraulics : 2 lifting cylinder / 2 tilting cylinder
Platform overlap with floor : - 44 mm
Lift arm pitch /Lift arm length : 460 / 1120 / 1240
Load centre - lengthwise : 600
mm
Load centre - across center : Central 50% of rated load on one side
Inclination angle of the platform : +90° to -10°
|
|
Platform type |
Platform width |
platform height |
Dead Weight |
Dead Weight |
|
|
|
210 kg
|
1450 mm
|
2100 mm
|
alu |
- |
* |
|
|
216 kg
|
1600 mm
|
2100 mm
|
alu |
- |
* |
| a (mm) |
Q (kg) |
| 750 |
500 |
| 650 |
430 |
| 550 |
360 |
| 400 |
260 |
| Lift arms (in mm) |
550 |
680 |
| H (max.) Loading height unloaded |
990 |
1190 |
| H (min.) Loading height loaded |
700 |
880 |
| F (max.) Middle of main beam to upper edge of loading floor |
540 |
640 |
| K (min.) at dimension F (max.) |
419 |
503 |
| D (min.) Installation space (min.) |
517 |
601 |
| D (max.) Installation space (max.) |
663 |
722 |
| F (min.) |
370 |
490 |
| K (max.) at dimension F (min.) |
555 |
624 |
| G (max.) Unloaded (middle of main beam to ground) |
450 |
550 |
| G (min.) loaded |
330 |
390 |
The specified weights apply to the lightest platforms of the corresponding height. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
