• Torsion-resistant two-cylinder lifting mechanism (main-beam
   concept) with parallel movement to the floor
• Simple installation thanks to bolted mounting plates
• Mounting plates interchangeable with C 750 S for stocking
  purposes

Available for :

• Mercedes-Benz Sprinter 3/5
• Volkswagen Crafter 30 /35 /50
• Iveco Daily (C-Profile) 35C-72C
• Citoen Jumper (Relay)
• Fiat Ducato / Pugeot Boxer
• Ford Transit 330-470 V363
• Renault Master X62 FWD/RWD
• Further vehicle types on request
Main beam : 120 x 80 mm
Lifting gear hydraulics : 1 lifting cylinder / 1 tilting cylinder
Platform overlap with floor : -57 mm
Lift arm pitch /Lift arm length : 620 mm
Load centre - across center : Central 50% of rated load on one side
Inclination angle of the platform : +90° to -10
Platform type Platform width platform height Dead Weight Dead Weight

199 kg 1450 mm 2100 mm alu  -
a (mm) Q (kg)
600 750
700 650
820 550
1120 400



Lift arms (in mm) 600
H (max.) Loading height unloaded 1080
H (min.) Loading height loaded 680
F (max.) Middle of main beam to upper edge of loading floor 580
K (min.) at dimension F (max.) 443
D (min.) Installation space (min.) 565
D (max.) Installation space (max.) 700
F (min.) 470
K (max.) at dimension F (min.) 578
G (max.) Unloaded (middle of main beam to ground) 500
G (min.) loaded 260



The specified weights apply to the lightest platforms of the corresponding height. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
