- Specially developed for the demands of the food and beverage industry, for example
- 2,500 kg lifting capacity with 1,000 mm load distance
- Robust four-cylinder lifting mechanism
- Either with steel or aluminium platform
- Optionally with clamped installation for I-beams
- Large selection of special equipment available
Lifting capacity : 2500
kg
Main beam : 180 x 180 mm
Lifting gear hydraulics : 2 lifting cylinder / 2 tilting cylinder
Platform overlap with floor : - 72 mm
Lift arm pitch /Lift arm length : 1300 mm
Load centre - lengthwise : 1000
mm
Load centre - across center : Central 50% of rated load on one side
Inclination angle of the platform : 90° to -10
| Platform type | Platform width | platform height | Dead Weight | Dead Weight |
| 690 kg | 2050 mm | 2500 mm | alu | - |
| 772 kg | 2400 mm | 2500 mm | alu | - |
| 880 kg | 2009 mm | 2500 mm | steel | - |
| 941 kg | 2409 mm | 2500 mm | steel | - |
| a (mm) | Q (kg) |
| 1000 | 2500 |
| 1400 | 1785 |
| 1600 | 1560 |
| 1800 | 1385 |
Feasibility study
Webtool for automatic feasibility study for C- Type Lifts
Here you can create your feasibility study drawing online. For an extensive range of vehicles, quickly and without obligation
Dimensions
| Lift arms (in mm) | 900 |
| H (max.) Loading height unloaded | 1554 |
| H (min.) Loading height loaded | 990 |
| F (max.) Middle of main beam to upper edge of loading floor | 924 |
| K (min.) at dimension F (max.) | 655 |
| D (min.) Installation space (min.) | 846 |
| D (max.) Installation space (max.) | 1111 |
| F (min.) | 600 |
| K (max.) at dimension F (min.) | 920 |
| G (max.) Unloaded (middle of main beam to ground) | 630 |
| G (min.) loaded | 390 |
The specified weights apply to the lightest platforms of the corresponding height. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
